Chinese professional 100L 200L 300L 500L high quality stainless steel beer fermentation tank made of supplier ZZ

Fermentation tanks store beer after the mash process of beer, and realize the fermentation process of beer by controlling the fermentation temperature through equipment. It can be said that fermentation is the most important part that affects the taste of beer. The color of fermented beer is attractive, so the requirements on the fermentation tank will be very strict. According to the appearance form, it can be divided into two types: vertical fermentation tank and horizontal fermentation tank. We will design and produce fermentation tanks for customers according to the actual needs of customers and the layout of the customer's on-site room.

The picture shows the 100L Vertical fermentation tank，equiped with temperature sensor in the bottom of the tank,the temperature can be measured and controled automaticly.in the bottom of the tank,there is also sample outlet,with sample valves in it,it is easy to check the state of beer in the fermenter,easy to operate.

The fermenter is jacketed, which can realize the temperature control in the tank, and is equipped with an insulation layer, which is covered with cold water pipes, which integrates insulation and cooling.

10% capacity. The upper part of the tank cylinder is flush with the bottom of the washing ball,7. Equipped with a washing ball, the installation position is slightly lower than the welding seam between the cylinder and the head, and the cleaning tube is Ø32.

Internal roughness ≤ 0.4um, and no deformation or scratches, 2B side of the weld.

 Manholes and positive and negative pressure safety valves are installed on the upper part, DN102 hop dry inlet, single head.

 The tank is equipped with temperature sensor (-10--150 ℃, 4-20mA signal, L = 200mm, 50.5 chuck connection, brand Fred), sampling valve; sewage outlet at the bottom, wine outlet valve at the bottom of the cone .

 The 2B surface inside the equipment, pickling passivation treatment, external surface brushing treatment, beautiful appearance, pipeline layout, opening position, etc. meet the requirements of operation, site installation and visit.
